Infrastructure Layers

The following diagram shows the different infrastructure layers of an on-prem/hybrid/BYOC MAM solution on the left. It starts with virtual or bare-metal machines on the bottom on which further layers are installed: operating system, container runtime, and the Kubernetes cluster on top.

The Kubernetes cluster is the place where all products for building an on-prem/hybrid/BYOC MAM solution are installed.

The column on the right shows further infrastructure in the customer’s environment which are prerequisites for properly configuring an operating an on-prem/hybrid/BYOC MAM solution.

Depending on the functional requirements to be implemented, additional infrastructure components may be required.
